ZC-MHHPA is a liquid anhydride curing agent for epoxy resins (assay ≥ 98.0%). Compared with conventional methyl tetrahydrophthalic anhydride (MTHPA), it cures to a lighter color, offers a higher glass transition temperature and cures slightly faster. It is used in dry-type transformers, high-voltage switches, instrument transformers, capacitors and LEDs.
Product Specificaiton
ZC-MHHPA is a colorless, transparent liquid anhydride curing agent for epoxy resins (molecular formula C9H12O3, molecular weight 168.19). It has a purity of at least 98.0%, a color of 50 Hazen (Pt-Co) or lower, a viscosity of 50–80 mPa·s at 25°C and a crystallization point of -15°C or lower.
- Compared with conventional methyl tetrahydrophthalic anhydride (MTHPA), ZC-MHHPA offers:
- Light color after curing, suitable for white or colorless transparent products
- Good heat resistance, with a glass transition temperature (Tg) higher than that of conventional MTHPA
Slightly faster curing, which helps reduce the amount of accelerator required
It has a slightly higher viscosity and somewhat greater moisture absorption than conventional MTHPA, so containers should be kept tightly sealed during storage.
| Item | Specification |
| Appearance | Colorless, transparent liquid |
| Color (Pt-Co), Hazen | ≤50 |
| Assay, % | ≥98.0 |
| Iodine Value, g I₂ /100 g | ≥ 41.0 |
| Viscosity (25°C), mPa·s | 50-80 |
| Crystallization Point, °C | ≤ −15 |
Applicaiton
Epoxy resin curing agent for:
-Dry-type transformers
-High-voltage switches
-Instrument transformers
-Capacitors
-Light-emitting diodes (LEDs)
Other electrical and electronic applications
-Suitable where a light-colored or colorless transparent cured product is required.
